Axon Exchange - IEDs integration platform

Axon Exchange is a solution whose main function is to serve as a gateway automation platform which collects data from any IEDs inside a substation. This allows the conversion between multiple communication protocols of telecontrol and facilitates the integration and automation of Substation systems. It concentrates and processes data in real time from connections through serial channels and Ethernet, and then reports it to SCADA systems or Control Centers. It is a highly interoperable system with IEDs of different types and brands, it also enables configurations in redundant mode and has a module which supports PRP (Parallel Redundancy Protocol). In addition, it has access control management mechanisms and implements various cybersecurity topics.

Download Gateway – Axon Exchange Brochure

It supports a logic module that allows you to implement special data type conversions and behavior management through functions and scripts. It has a remote visualization tool of the signal status that allows management of the connections and their status. It is flexible and the modular architecture enables a scalable evolution of solutions.

Numbers talk about us

Technological automation solutions focused on the electrical industry

Years of experience
0
Licenses software in the market
+ 0
Time saving of engineering
0 %

Key Features:

Protocols

  1. IEC 61850
  2. ICCP / TASE.2
  3. DNP3 LAN / WAN
  4. DNP3 Serial
  5. IEC 60870-5-104
  6. IEC 60870-5-104 (Endesa profile)
  7. IEC 60870-5-101 Serial / Over TCP
  8. OPC
  9. Modbus
  10. Fast Message (SEL)

Features

Communications gateway with intuitive interface for project configuration that allows the creation and parameterization of master / client and slave / server devices of multiple telecontrol protocols in an easy and fast way.

FAQ

You have doubts? Solve them here.

In the Axon Exchange Config window, in the project explorer, when clicking on the project name, the option to enable SOE (Sequence of Events) and the directory on which the file will be created is displayed in the properties window.

  • IsLocal: Indicates whether it has the local token or is in a remote state.
  • Level: Access level, the highest priority is represented by the smallest number.
  • Local/Remote State: Displays the identifier of the person who requested the local token.
  • Local/Remote Command: Assignment command for Local or remote status.

Templates were created to optimize the creation of devices which have the same signal configuration. Templates allow the creation of mapping (all the signals with their characteristics) to be associated with devices, in this way it is not necessary to create the signals in each communication.

Through the logics in the master, it is possible to receive two single signals and convert them into a double signal that will be reported to the slave or receive a double signal that will be reported as two single signals.

After locating the project name in the Axon Exchange Viewer explorer, the information associated with the connected license is displayed on the properties panel.

Más Recursos

Axon Group

Gateway de comunicaciones Axon Exchange

¿Cómo configurar bahías eléctricas de un mismo tipo con Axon Exchange?

¿Cómo configurar en segundos el control de una bahía redundante con Axon Exchange?

Simulator IEC 61850
Backup Manager
It is a system for monitoring channels
Protocol simulator

Contact us

Do you need support on your engineering projects?

To be able to download the content for free you must log in:

System requirements

Axon Exchange

  • Operating systems: Windows 10, Windows Server 2012 or higher.WINPCAP and NPCAP.
  • Framework: Microsoft .NET 4.5 SP2.
  • Component: Microsoft Visual C++ 2010, 2013, 2015.
  • Hard Drive: 4 GB free.
  • Processor: Intel Core i5 o superior.
  • RAM: 4 GB.
